3D Robot Radar
3D Robot Radar
Get the best in technology and take control of your processes today!
Our 3D Robot Radar is the world’s first rotating 3D radar designed to measure level, volume, and create a real-time 3D profile of materials in silos, bunkers, and stockpiles. Operating at a high frequency of 140 GHz and powered by advanced algorithms, it scans multiple points across the material’s surface to generate a highly accurate representation, providing precise data on level, volume, mass, and material profiles.
Request a Quote
Industries Served How It Works
It works by taking multiple point measurements inside the silo or stockpile, and plotting the X, Y, and Z coordinates of the material. Using this data, it generates a real-time 3D profile of the material, along with accurate measurements of its level, volume, and mass, calculated based on the material’s density.
During each scanning cycle, the radar captures an almost unlimited number of points (as defined by the use), delivering exceptional accuracy for both hard and soft bulk materials. The proprietary 3D software then calculates volumes, publishes the reports, and provides a graphic interface. Scan results are immediately available without any need for additional calibrations or calculations.
Specifications
Preferred Applications: Powders and Solids
Measuring Range: 100 meters
Operating Temperatures: : –40°C to +400°C
Operating Pressure: -0.2 to 40 bar
Signal Output Options: 4-wire 4 – 20 mA/HART/RS-485/Modbus
Measurement Points: Configurable and can be set up to 200 points or more
Emitting Frequency: 140 GHz for each beam
Supply Voltage: 20 to 32 VDC (110/ 230 VAC through SMPS)
Power Consumption: Max 8 W @ 24 VDC
